┌──(root㉿kali)-[~/miaosec] └─# nmap -sn 192.168.2.0/24 Starting Nmap 7.98 ( https://nmap.org ) at 2026-01-21 10:58 +0800 Nmap scan report for 192.168.2.1 Host is up (0.0012s latency). MAC Address: 0A:00:27:00:00:07 (Unknown) Nmap scan report for 192.168.2.2 Host is up (0.00066s latency). MAC Address: 08:00:27:75:F0:11 (Oracle VirtualBox virtual NIC) Nmap scan report for 192.168.2.53 Host is up (0.00071s latency). MAC Address: 08:00:27:0C:6B:7C (Oracle VirtualBox virtual NIC) Nmap scan report for 192.168.2.4 Host is up. Nmap done: 256 IP addresses (4 hosts up) scanned in 7.63 seconds
靶机IP:192.168.2.53
2、端口扫描
1.全端口扫描
1 2 3 4 5 6 7 8 9 10 11 12 13
┌──(root㉿kali)-[~/miaosec] └─# nmap --min-rate 10000 -p- 192.168.2.53 Starting Nmap 7.98 ( https://nmap.org ) at 2026-01-21 10:58 +0800 Nmap scan report for 192.168.2.53 Host is up (0.00036s latency). Not shown: 65532 closed tcp ports (reset) PORT STATE SERVICE 22/tcp open ssh 80/tcp open http 5000/tcp open upnp MAC Address: 08:00:27:0C:6B:7C (Oracle VirtualBox virtual NIC)
Nmap done: 1 IP address (1 host up) scanned in 36.13 seconds
┌──(root㉿kali)-[~/miaosec] └─# nmap --min-rate 10000 -sT -sC -sV -O -p22,80,5000 192.168.2.53 Starting Nmap 7.98 ( https://nmap.org ) at 2026-01-21 10:59 +0800 Nmap scan report for 192.168.2.53 Host is up (0.0011s latency).
PORT STATE SERVICE VERSION 22/tcp open ssh OpenSSH 9.2p1 Debian 2 (protocol 2.0) | ssh-hostkey: | 256 3a:dc:d6:1d:84:b6:96:c0:8f:96:1e:65:a0:24:0e:fb (ECDSA) |_ 256 de:93:17:fb:3a:19:9c:e0:17:32:2d:a9:73:f7:c5:94 (ED25519) 80/tcp open http Apache httpd 2.4.57 ((Debian)) |_http-server-header: Apache/2.4.57 (Debian) |_http-title: Apache2 Debian Default Page: It works 5000/tcp open http Node.js (Express middleware) |_http-title: VulNyx Lab MAC Address: 08:00:27:0C:6B:7C (Oracle VirtualBox virtual NIC) Warning: OSScan results may be unreliable because we could not find at least 1 open and 1 closed port Device type: general purpose|router Running: Linux 4.X|5.X, MikroTik RouterOS 7.X OS CPE: cpe:/o:linux:linux_kernel:4 cpe:/o:linux:linux_kernel:5 cpe:/o:mikrotik:routeros:7 cpe:/o:linux:linux_kernel:5.6.3 OS details: Linux 4.15 - 5.19, OpenWrt 21.02 (Linux 5.4), MikroTik RouterOS 7.2 - 7.5 (Linux 5.6.3) Network Distance: 1 hop Service Info: OS: Linux; CPE: cpe:/o:linux:linux_kernel
OS and Service detection performed. Please report any incorrect results at https://nmap.org/submit/ . Nmap done: 1 IP address (1 host up) scanned in 16.47 seconds
3.udp扫描
1 2 3 4 5 6 7 8 9 10
┌──(root㉿kali)-[~/miaosec] └─# nmap -sU --top-ports 100 192.168.2.53 Starting Nmap 7.98 ( https://nmap.org ) at 2026-01-21 11:00 +0800 Nmap scan report for 192.168.2.53 Host is up (0.00091s latency). All 100 scanned ports on 192.168.2.53 are in ignored states. Not shown: 57 closed udp ports (port-unreach), 43 open|filtered udp ports (no-response) MAC Address: 08:00:27:0C:6B:7C (Oracle VirtualBox virtual NIC)
Nmap done: 1 IP address (1 host up) scanned in 57.08 seconds
